Welded metal bellows seals continue to have success as a core sealing technology and have gained popularity recently in new innovative sealing technologies such as high-temperature non-contacting gas lubricated seals and high-temperature corrosion resistant seals.
TYPE LTS-MT41GB : is Inherently balanced metal bellow seal. This seals are independent of direction of rotation. The unique feature of this type of seal is that, there is no dynamic 'O' rings and therefore it will never hangup or damage the shaft and sleeve.
TYPE LTS-MT41GB : is Inherently balanced metal bellow seal. This seals are independent of direction of rotation. The unique feature of this type of seal is that, there is no dynamic 'O' rings and therefore it will never hangup or damage the shaft and sleeve.
WELDED ENDS METAL BELLOW SEAL
TYPE LTS-MT41GB
Generally used in for handling highly corrosive chemicals, high Temperature applications, etc.
Applications :
Materials :
Seal Faces : Carbon/TC/ Vs Sic./Tc
Secondary Seals : Viton/PTFE/ GFT/Graphite
Metal Components : SS-316
Secondary Seals : Viton/PTFE/ GFT/Graphite
Metal Components : SS-316
Operating Limits :
Shaft Diameter
Pressure
Temperature
Speed
Pressure
Temperature
Speed
: 19 to 100mm
: up to 15 Bars
: -50 to 350°C
: up to 25 m/s
: up to 15 Bars
: -50 to 350°C
: up to 25 m/s
Hast-alloy-C
AM305
Alloy C 276
Alloy 20
Inconel 625
AM305
Alloy C 276
Alloy 20
Inconel 625
Bellow Material :
