PRODUCT RANGE
TYPE LTS-72HF : are single coil unbalanced seals, these seals are simple in design & reliable & rugged enough for the most difficult applications. In LTS-72HF 'V" packing used as Secondary seals respectively. Special notches enhance the required driving torque & hence the seal is Independent of direction of rotation. Owing to the support of sound infrastructure and dedicated workforce, we are able to manufacture, export and wholesale Single Coil Spring Unbalance Seal.
SINGLE COIL SPRING UNBALANCED SEAL
TYPE - LTS72HF
Generally used in refineries, fertilizers, nuclear plants & petroleum pipelines.
Applications :
Materials :
Seal Faces : Carbon/TC/Sic. Vs Ceramic/RB Sic./Tc
Secondary Seals : Viton/PTFE/GFT
Metal Components : SS-316
Secondary Seals : Viton/PTFE/GFT
Metal Components : SS-316
Operating Limits :
Shaft Diameter
Pressure
Temperature
Speed
Pressure
Temperature
Speed
: 25 to 150mm
: up to 10 Bars
: -50 to 280°C
: up to 15 m/s
: up to 10 Bars
: -50 to 280°C
: up to 15 m/s
